Plastic Basket Making Machine
MACHINE MODEL: LOG 1100 TON
TYPE: SERVO SYSTEM
CLAMPING FORCE: 11000 KN
PART: FRUIT BASKET
CAVITY: 1
MATERIAL: PP
PRODUCT DIMENSION: 600*420*300mm
PRODUCT WEIGHT: 1350g
(How to choose a plastic basket making machine,watch the video below.)
| Model | LOG-1100 | |||
|---|---|---|---|---|
| International Recognition Number | (9080/1100) | |||
| Injection System | A | B | C | D |
| Theoretical Volume | 4123 | 4989 | 5938 | 6968 |
| Actual Injection Volume | 3751 | 4540 | 5403 | 6340 |
| 132.8 | 160.8 | 191.4 | 224.5 | |
| Injection Speed | 702 | 850 | 1010 | 1186 |
| Injection Rate | 380 | 453 | 532 | 578 |
| Screw Diameter | 100 | 110 | 120 | 130 |
| Injection Pressure | 220 | 182 | 153 | 130 |
| Aspect Ratio | 24.2:1 | 22:1 | 20.2：1 | 18.6:1 |
| Screw Stroke | 525 | |||
| Screw Speed | 0-110 | |||
| Clamping System | ||||
| Clamping Force | 11000 | |||
| Mold Opening Stroke | 1150 | |||
| Template Size | 1650*1650 | |||
| Connecting Rod Inner Distance | 1150*1100 | |||
| Bulk Modulus | 450-1200 | |||
| Template Maximum Stroke | 2350 | |||
| Hydraulic Ejection Stroke | 350 | |||
| Hydraulic Ejection Force | 270 | |||
| Power / Electric Heat | ||||
| Hydraulic System Pressure | 17.5 | |||
| Oil Pump Motor | 45+45/56+56 | |||
| Electric Heat | 58.85 | |||
| Number of Heating Control Zones | 6+ nozzle | |||
| Other | ||||
| Cycle Time | 10 | |||
| Fuel Tank Capacity | 2300 | |||
| Mechanical Dimensions | 12.5*2.8*3.5 | |||
| Theoretical Machine Weight | 60000 | |||
Vedio:
