Plastic Spoon Making Machine
Plastic Spoon Making Machine - 250 Ton Injection Molding Machine
| Model | LOG-250 | ||
|---|---|---|---|
| International Recognition Number | 1140/250 | ||
| Injection System | A | B | C |
| Theoretical Volume | 510 | 687 | 863 |
| Actual Injection Volume | 464 | 625 | 785 |
| 16.2 | 21.8 | 27.4 | |
| Injection Speed | 175 | 236 | 297 |
| Injection Rate | 103 | 139 | 174 |
| Screw Diameter | 50 | 58 | 65 |
| Injection Pressure | 224 | ||
| Aspect Ratio | 24；1 | ||
| Screw Stroke | 260 | ||
| Screw Speed | 0-180 | ||
| Clamping System | |||
| Clamping Force | 2500 | ||
| Mold Opening Stroke | 520 | ||
| Template Size | 820*790 | ||
| Connecting Rod Inner Distance | 560*530 | ||
| Bulk Modulus | 200-580 | ||
| Template Maximum Stroke | 1100 | ||
| Hydraulic Ejection Stroke | 150 | ||
| Hydraulic Ejection Force | 67 | ||
| Power / Electric Heat | |||
| Hydraulic System Pressure | 17.5 | ||
| Oil Pump Motor | 22/39 | ||
| Electric Heat | 16 | ||
| Number of Heating Control Zones | 4+ nozzle | ||
| Other | |||
| Cycle Time | 4.8 | ||
| Fuel Tank Capacity | 350 | ||
| Mechanical Dimensions | 6.2*1.46*2.15 | ||
| Theoretical Machine Weight | 8000 | ||
(How to choose a plastic spoon injection molding machine,watch the video below.)
